APPLICATION :
- Provides slurry for oilfield use.
- Used to set up a portable mixing plant.
The Mixing Tank is made of 2 tanks (15m3 + 35m3), 1 Control Panel, Triple Pump Drive, Hydraulic Components with oil tank including level gauge, cooling radiator, filtering etc.…. and is specifically design to mix cement, bentonite, liquid additives etc… for oilfield use.
The Mixing Tank is a recirculating mixer powered by Diesel Engine.
The energy is provided to slurry through 1 centrifugal pump 4 x 3, venturi mixing jet and agitators.
| OVERALL DIMENSIONS | ||
|---|---|---|
| Length | 13000 mm | 42 Ft |
| Width | 2500 mm | 8 Ft |
| Height | 3000 mm | 10 Ft |
| Dry Weight | 20000 kg | 40000 Lbs |
| ENGINE & TRANSMISSION | ||
| Engine type | Detroit diesel 4-53 N (or equivalent Caterpillar) | |
| Triple pump drive | Funk | |
| Cooling system | Air Cooler & Fan | |
| Hydraulic Power | 185 BHP@2500 RPM | |
| AGITATORS | ||
| Type | TMI MTA 2 51 1206-12-2803 | |
| OTHER | ||
| Fill Line | One Side | |
| Discharge manifold | One Side | |
| Hydraulic components | DENISON | |
| Centrifugal Pump | Mission or others |
OPTIONS :
Special design and equipment on request.
| SPN | DESCRIPTION | CAPACITY |
|---|---|---|
| M.I. -TA / 31-15 | MIXING TANK (35 m3 + 15 m3) | 220 BBL + 95 BBL |
